Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194215-12341 Nut 2
2 CY-1A7531-17541 Cylinder Assy, Steer 1
3 CY-1A7335-17520 Circlip 120 1
4 CY-1A7335-17530 Circlip 120 1
5 CY-1A7500-17551 Seal Kit 1
6 CY-1A7500-17560 Rock Nut 1
7 CY-1A7500-17570 Piston 1
8 CY-1A7500-17580 Cap, Cylinder 1
9 CY-1A7510-17590 Rod Assy 1
10 CY-198165-17781 Elbo, 1/4X1/4 1
11 CY-22417-250250 Cotter Pin 2.5X25 2
67
FIG. 23. PST CYLINDER
