Cub Cadet Yanmar Sx3100 - Boom

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1TN325-21000 Boom Cmp 1
2 CY-1TN325-73110 1-115 Pin 4
3 CY-24761-010000 Nipple M6F, Grease 4
4 CY-26116-060502 Bolt M 6X 50 Plated 4
5 CY-26347-060002 U-Nut M 6 4
182
FIG. 5. BOOM
