Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7530-17300 Valve Assy, Steering 1
2 CY-1A7510-17310 Bolt 4
3 CY-1A7530-17410 Column Set 1
4 CY-1A7510-17470 Boot, Steerring 1
5 CY-1A6770-17510 Plate, St Colum 1
6 CY-1A7530-17550 Stay,Steering 1
7 CY-1A7530-17571 Rubber,Sts 1
8 CY-1A7500-17910 Plate 1
9 CY-22137-160000 Washer 16,Polished 1
10 CY-22157-100000 Washer 10 4
11 CY-22217-100000 Spring Washer 10 8
12 CY-26013-080202 Bolt W/Washer M8X20 2
13 CY-26018-100202 Bolt M10X20 2
14 CY-26736-100002 Nut M10 4
15 CY-26776-160002 Lock Nut M16 Plated 1
66
FIG. 22. PST VALVE
