Cub Cadet Yanmar Sx3100 - Exhaust Manifold & Muffler

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129232-13100 Manifold, Exhaust 1
2 CY-129150-13110 Gasket, Exh.Manifold 1
3 CY-123900-13610 Stud Bolt M 8X 80 2
4 CY-123900-13630 Bolt 8X80 1
5 CY-119802-13640 Bolt, M8X60 2
6 CY-123900-13650 Bolt M8X110 1
7 CY-119131-18320 Bolt M 8X 22 4
8 CY-26306-080002 Nut 2
9 CY-119515-13200 Gasket, Muffler 1
10 CY-129055-13521 Muffler 1
11 CY-26306-080002 Nut 4
14
FIG. 6. EXHAUST MANIFOLD & MUFFLER
