Cub Cadet Yanmar Sx3100 - Page 13

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129005-03080
Pipe, Breather
1
2 CY-129410-03990
Clamp 22 2
3 CY-129005-12100
Manifold, Intake 1
4 CY-129001-12110
Gasket,Int. Manifold
1
5 CY-26106-080202 Bolt M 8X 20 Plated 4
6 CY-26106-080802
Bolt M 8X 80 Plated
1
7 CY-129486-12581 Joint 1
8 CY-129150-77511
Gasket, (Non-Asb.) 1
9 CY-26106-080202
Bolt M 8X 20 Plated 3
10 CY-119934-12200
Pipe, Intake 1
11 CY-119934-12501
Cleaner Assy, Air 1
12 CY-119934-12510
Body, Air Cleaner 1
13 CY-119808-12520
Element, Outer 1
15 CY-129051-12530
Element, Inner
1
16 CY-129418-12530
Mark 2
17 CY-119808-12540
Valve, Unloader 1
18 CY-119866-12541
Cover Assy 1
19 CY-129612-12650
Marking,(W) 1
20 CY-119865-12600
Stay 1
24 CY-129232-12601
Support, Cleaner
1
25 CY-23000-060000
Clamp 60 2
26 CY-26106-080122
Bolt M 8X 12 Plated
1
27 CY-26106-080502
Bolt M 8X 50 Plated
1
28 CY-26306-080002
Nut
2
13
FIG. 5. SUCTION MANIFOLD & AIR CLEANER
