Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198167-25080 Collar Set,Spl H/L 1
2 CY-198167-25750 Spline Collar, H/L 1
3 CY-198167-25770 Collar, Shift 1
4 CY-194856-25330 Washer 22X32X2.5 2
5 CY-1A7540-25710 Shaft, Counter 1
6 CY-1A7540-25730 Gear(Counter High 1
7 CY-1A7540-25740 Gear, Counter Low 1
8 CY-198165-25810 Bearing 6206Rsh2 1
9 CY-198165-25840 Collar 30*38*4.5 1
10 CY-1E6190-54430 Thrust Washer (C) 2
11 CY-1E6820-54560 Circlip 22 2
12 CY-22242-000250 Circlip 25S 1
13 CY-22242-000290 Circlip 29 1
14 CY-22292-000240 Circlip S-24 1
84
FIG. 36. COUNTER SHAFT
