Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129150-01881 Gasket, (Non Asb.) 1
2 CY-129150-26000 Driving Set, Ho-Pump 1
3 CY-129150-26050 Bracket, Ho-P 1
5 CY-24105-060064 Ball Bearing 2
6 CY-124240-01883 Gasket, (Non-Asb.) 1
7 CY-119626-26690 Spacer 1
8 CY-198220-48140 Flange 1
9 CY-24311-000200 O-Ring 1A P-20.0 1
10 CY-26106-060402 Bolt M 6X 40 Plated 3
11 CY-26106-080952 Bolt M 8X 95 Plated 2
12 CY-26216-080402 Stud M 8X 40 Plated 1
13 CY-26306-080002 Nut 2
14 CY-119923-26010 Pump, Hydraulic 1
19
FIG. 9. HYDRAULIC PUMP
