Cub Cadet Yanmar Sx3100 - Front Tire R4

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8300-14800 Tire Kit, Front L R4 1
2 CY-1A8300-14820 Tire, 23X8.5-12 R4 1
3 CY-1A8300-14830 Wheel, 1
4 CY-1A8300-14840 Valve, 1
5 CY-1A8300-14810 Tire Kit, Front R R4 1
6 CY-1A8300-14820 Tire, 23X8.5-12 R4 1
7 CY-1A8300-14830 Wheel, 1
8 CY-1A8300-14840 Valve, 1
63
FIG. 19. FRONT TIRE R4
