Cub Cadet Yanmar Sx3100 - Transmission Section

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7540-21100 Housing Assy, Clutch 1
2 CY-1A6680-21120 Stay Cmp, Switch 1
3 CY-1A6680-21200 Stop Cmp 1
4 CY-1A6680-21250 Stay, F Rest L 2
5 CY-26016-080202 Bolt M 8X 20 8
6 CY-1A6680-21460 Rubber, Cap 25 1
7 CY-194151-36670 Plug Pt02 1
8 CY-1E6102-83230 Clamp,Battery Cable 1
9 CY-26016-080352 Bolt M 8X 35 14
71
FIG. 26. CLUTCH HOUSING
