REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194215-04220 Spacer 8X10X10 2

2 CY-198165-04380 Rubber, 100X25X3 1

3 CY-1A7530-21210 Rubber,St 2

4 CY-194990-22050 Nut W/Washer 8 1

5 CY-194990-22140 Nut W/Washer 8 4

6 CY-1A7530-61420 Bonnet Stand Assy 1

7 CY-1A7540-61450 Stay Cmp, Rod 1

8 CY-1A7540-61500 Stay Assy, Dashboard 1

9 CY-198200-61550 Stopper, Stand 1

10 CY-1A7540-61580 Spacer 1

11 CY-1A7540-61590 Plate,Eng 1

12 CY-1A7510-61610 Dashboard(Upper 1

13 CY-1A8300-61650 Dashboard Assy,Lower 1

14 CY-198165-64260 Seal E 2

15 CY-1A7510-61670 Stay,Db Lower 1

16 CY-1A7531-61801 Plate Cmp, Air Cut 1

17 CY-1A7510-61850 Seal, Dashboard 1

18 CY-1E6910-83500 Grommet 30 W/Film 1

19 CY-22372-080000 Snap Pin (Jaso 8) 2

20 CY-26018-060162 Bolt M6X16 6

21 CY-26018-060162 Bolt M6X16 4

22 CY-26018-080162 Bolt M 8X 16 2

23 CY-26018-080202 Bolt M 8X 20 4

24 CY-26018-080202 Bolt M 8X 20 2

25 CY-26018-080252 Bolt M8X 25 2

151

FIG. 84. DASHBOARD

Cub Cadet Yanmar Sx3100 User Manual
