Sx Series

Sx3100

REF

NO.

PART NUMBER DESCRIPTION QTY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-729008-01500 Gear Case Assy 1 14 CY-24311-000320 O-Ring 1A P-32.0 1

3 CY-119934-01800 Seal, Oil 1 15 CY-26106-080162 Bolt M 8X 16 Plated 4

4 CY-129008-01520 Flange, Gear Case 1 16 CY-26106-080162 Bolt M 8X 16 Plated 3

5 CY-119802-01561 Stud, M8X25 3 17 CY-26106-080302 Bolt M 8X 30 Plated 1

6 CY-129150-01580 Stud 8 X 30 1 18 CY-26106-080552 Bolt M 8X 55 Plated 10

7 CY-124160-01751 Cover,Filler 1 19 CY-26306-080002 Nut 3

8 CY-124240-01871 Cover, Ho-P 1 20 CY-124240-01871 Cover, Ho-P 1

9 CY-119609-32040 O-Ring P16 2 21 CY-124240-01883 Gasket, (Non-Asb.) 1

10 CY-121850-51960 O-Ring, F.I.Pump 1 22 CY-26106-080122 Bolt M 8X 12 Plated 4

11 CY-26106-080852 Bolt M 8X 85 Plated 3 23 CY-129150-91400 Gear Unit,Tachometer 1

12 CY-22190-080002 Seal Washer 8S 4 25 CY-24341-000240 O-Ring 1A S-24.0 1

13 CY-22190-080002 Seal Washer 8S 1 26 CY-26106-060162 Bolt M 6X 16 Plated 2

FIG. 2. GEAR HOUSING

Cub Cadet Yanmar Sx3100 User Manual
