Communication Port Diagram
The following diagram shows the communication ports located on the back of the machine.
Radio frequency present.
Install ferrite bead on all external communication cables; position
ferrite bead near external port.
Only connect Ethernet cable to Ethernet port.
Use of any other cable may damage equipment.
DB9 serial port
FireWire port
(non-functional)
Two USB ports
Ethernet port
