GenesisPlus Operator Manual
D1151, R
EV C, 10/16
Connecting the System Components
Before connecting the GenesisPlus system components, inspect the individual components,
cables and electrical connections for any dirt, debris or damage. Check all electrical cables to
ensure they are not frayed or split. Inspect the handpiece, as instructed in the Maintenance sec-
tion of this operator manual.
WARNING
Always turn off the system before inspection of the handpiece.
Never look directly into the handpiece even when wearing protec-
tive eyewear. Never look directly into the laser beam or at scattered
light from metallic or other reflective surfaces. The 1064 nm
Nd:YAG laser beam can cause permanent eye damage.
NOTE
Do not touch the window on the handpiece; finger oils may damage
the
coating.
Connecting the Footswitch
Plug the footswitch cable into the footswitch receptacle on the rear of the system con-
sole. If the footswitch is not properly connected when the system is turned on, a pop-up screen
with an animated illustration will be displayed on the touchscreen and the system cannot be
placed into READY mode. An illustration of the pop-up screen is displayed later in this chap-
ter.
Inserting the Remote Interlock Plug
Insert the remote interlock plug into the interlock receptacle on the rear of the system con-
sole. The remote interlock plug must be inserted into the interlock receptacle at all times,
whether or not an external door switch is used.
Connecting the Main Power Cable
1. Ensure that the system main power circuit breaker is OFF (down) and that the system key-
switch is in the O (OFF) position.
2. Insert the receptacle end of the power cable into the power cable receptacle on the system,
and insert the AC plug into the AC wall socket.
