41
GenesisPlus Operator Manual
D1151, R
EV C, 10/16
System Specifications
Specifications subject to change without notice.
Treatment Beam
Type High power, long pulse Nd:YAG
Wavelength 1064 nm (Nd:YAG)
Output ≤100 J Max.
Fluence
Genesis mode: 5 - 40 J/cm
2
Warts mode: 140 - 210 J/cm
2
Pulse Width Genesis mode: 0.1 - 1 ms
Warts mode: 6 - 20 ms
Repetition Rate Genesis mode: Single shot to 10 Hz
Warts mode: Single shot only
Delivery System Permanently attached umbilical and
handpiece
Treatment Spot 5 mm (0.2 in) fixed circular spot
Working Distance 3 - 4 cm (1.2 - 1.6 in)
System Cooling Self-contained, water to air heat
exchanger
Aiming and Working
Distance Beams
650 nm
Physical Parameters
Size (W X D X H): .33 m X .46 m X .96 m (13 in X. 18 in X. 38 in)
Weight: 61 kg (135 lb)
Operating length
of umbilical: 1.8 m (5.8 ft)
Minimum bend
radius of umbilical: Storage 12.6 cm (5 in)
Momentary 5 cm (2 in)
