iii
GenesisPlus Operator Manual
D1151, R
EV C, 10/16
CONTENTS
OPERATION 1
Introduction 1
System Preparation 2
GenesisPlus System Components 3
System Console 4
Footswitch 4
Remote Interlock Plug 4
Handpiece 4
Connecting the System Components 5
Connecting the Footswitch 5
Inserting the Remote Interlock Plug 5
Connecting the Main Power Cable 5
System Basics 7
Turning On the System 7
Restarting the System 7
Turning Off the System 7
Emergency Off 8
Disconnecting the System 8
Moving the System 8
General System Functions 10
Genesis Control Screen 10
Warts Control Screen 11
System Status: STANDBY and READY Modes 12
Treatment, Aiming and Working Distance Beams 14
Memory Storage 16
Thermal Monitoring 17
Information & Adjustment Screen 19
Audible Tones 20
Audible Pulse Counter 21
Pop-up Screen 22
Displays and Indicators 23
User-selectable Parameters 24
Selecting the Fluence 24
Selecting the Pulse Width 25
Selecting the Repetition Rate (Genesis mode only) 26
