D-Link DSL-520B User Manual

13D-Link DSL-520B ADSL2+ Modem User Manual
Section 6 - Quick Setup
Quick Setup
QuickSetupwillbetherstpageyouseewhenyoulogintotherouter.VerifytheboxischeckednexttoDSLAuto-connect.Pleaseprepareyour
account information provided by your Internet Service Provider (ISP).
Click Next to begin setup.
Note: Quick Setup will allow you to congure a PPPoE
connection. For more information on PPPoE and other
connectiontypes,pleaseseetheAdvancedSetupsection
in this user manual.

D-Link DSL-520B Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Interfaces

ADSL interface	RJ-11 connector
LAN interface	RJ-45 port
Ethernet	10/100BASE-T
