30D-Link DSL-520B ADSL2+ Modem User Manual
Section 9 - Advanced Setup
PPP over Ethernet (PPPoE)
This page allows you to congure your PPPoE connection.
PPP Username: Enter your username as provided by
your ISP.
PPP Password: Enter your password as provided by
your ISP.
PPP Service Name: Enter any name that will help you
identify your connection. This eld will not aect your
connection.
Dial on demand (with idle timeout timer): Allows
you to manually connect to the Internet so you are not
permanently connected. Idle timeout timer is included.
PPP IP extension: Used by some ISPs. Check with your
ISPtoseeifitisrequired.
Use Static IP Address: Select if your ISP has provided
youwithastaticIPaddress.Ifselected,youwillbeasked
to enter the static IP address.
Retry PPP password on authentication error: Select if you want the router to automatically retry your PPP username and password when there
is an authentication error on your DSL line.
Enable PPP Debug Mode: Select if you want to keep a log of connection negotiation transactions. This option is used for troubleshooting connection
issues.
Bridge PPPoE Frames Between WAN and Local Ports (Default Enabled): Use the default setting unless otherwise instructed by your ISP.
MTU: Use the default setting of 1492 unless otherwise instructed by your ISP.
Click Next.
