4D-Link DVA-5582 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 USB Green
On The connection of a 3G or USB device has been established.
Blinking Data is being transmitted.
O No connection of a 3G or USB device is established.
2 Phone (1/2)
Green
O No phone signal is detected.
Blinking Active call.
On The phone interface is ready.
Orange On No VoIP account registered.
3 5 GHz
Green
Blinking Data is being transmitted through the WLAN interface.
On The connection of WLAN interface is normal.
O The WLAN connection is not established.
Orange Blinking WPS pairing in Progress.
4 2.4 GHz
Green
Blinking Data is being transmitted through the WLAN interface.
On The connection of WLAN interface is normal.
O The WLAN connection is not established.
Orange Blinking WPS pairing in Progress.
4 5 62 3 71 8
