6D-Link M30 AX3000 Dual-Band Wi-Fi 6 Router User Manual
Section 1 - Product Overview
AX3000 Dual-Band Wi-Fi 6 Router Rear Panel
1 WPS Button
Press this button to establish an instant connection to a wireless client using Wi-Fi Protected Setup
(WPS).
2 Gigabit LAN Ports (1- 4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
3 Gigabit WAN Port Connect your broadband modem to this port using an Ethernet cable.
4 Reset Button
The reset button turns the router to default settings. Insert a paperclip into the hole, wait for the LED to
turn solid red, and then release.
5 Power Connector Connect the included power adapter here to power on the device.
6 Power Button Press the power button to power on or o the device.
7 LED ON/OFF Button Press and hold the LED ON/OFF Button for 3 seconds for the LED light on the front of the device.
1
2
3
4
5
6
7
