D-Link MYDLINK DNR-322L User Manual

27D-Link DNR-322L User Manual
Section 3 - Conguration
This section will show you how to congure your new D-Link NVR using the Web-based Conguration Utility.
To access the conguration utility, click the NVR name or IP on the NVR Search Utility or manually open a web-browser (Internet
Explorer only) and enter the IP address of your NVR.
The Login screen will appear:
When loggin to the NVR for the rst time, you will be asked to choose a drive conguration type and format the drives. There are
four options: Standard, JBOD, RAID 0 and RAID 1. Standard congures each disk as a separate volume, while JBOD combines
both disks into a single volume. See page 48 for more details on using the RAID congurations.
Note: Refer to page 45 for instructions on how to change the password of your admin account.
Click Login
Web UI Login
Type “admin”in theuser name eld and
leave the password blank by default.
Select display language

D-Link MYDLINK DNR-322L Specifications

Power

power adapter	DC 12V/4 A
max power consumption	25.20 W
standby state max power consumption	0.23 W

Operating Environment

operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
storage temperature	Operating: 5% to 90% (non-condensing)

Memory

flash rom	128 MB
ram	256 MB DDR II

Weight and Dimensions

dimension	4.53 x 5.76 x 7.03 inches (115 x 146.4 x 178.5 mm)
weight	0.875 kg (1.93 lbs)
