D-Link MYDLINK DNR-322L User Manual

49D-Link DNR-322L User Manual
Section 3 - Conguration
Creates two separate volumes (or one volume if
only one hard drive is present). Each hard drive
has its own volume.
Note:
Only Standard mode can create the Volume2,
which is available as a File (Samba) Server. Use
the NVR Search utility can mount the File server
to your Windows system.
Combines both hard drives in a linear fashion
which will create one large volume geared towards
maximum available space.
Combines both hard drives in a striped fashion
which will create one large volume geared towards
maximum performance.
Mirrors the hard drives for redundancy. If one hard
drive fails, the other still has all of the data. Replace
the failed hard drive and it will re-mirror, restoring
maximum data protection.
RAID
Standard:
JBOD:
RAID 0:
RAID 1:
NVR will show the information of installed HDD rst. Click Next to select new RAID conguration.
Choose from four dierent hard drive congurations in this section. Begin by clicking the Set RAID Type and Re-Format button.
Note: All data will be lost during this process.

D-Link MYDLINK DNR-322L Specifications

Power

power adapter	DC 12V/4 A
max power consumption	25.20 W
standby state max power consumption	0.23 W

Operating Environment

operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
storage temperature	Operating: 5% to 90% (non-condensing)

Memory

flash rom	128 MB
ram	256 MB DDR II

Weight and Dimensions

dimension	4.53 x 5.76 x 7.03 inches (115 x 146.4 x 178.5 mm)
weight	0.875 kg (1.93 lbs)
