D-Link MYDLINK DNR-322L User Manual

78D-Link DNR-322L User Manual
Section 3 - Conguration
Step forward/
Reverse:
Fast forward/
Reverse:
Click to pause the playback and move to next frame or last frame.
Click to pause the playback and move to next minute or last minute.
Set Connections to the Units
Step 1: Click the Remote Server button.
Step 2: Input the name of your unit.
Step 3: Input the IP address of that unit.
Step 4: Modify the port if necessary.
Step 5: Input the user name.
Step 6: Input the password.
Step 7: Check the Save Password option.
Step 8: Click the Test Server button to test the connection
between the local application and the remote unit.
Step 9: Click the Add button to add this
unit into the remote server list.
Step 10: Click the OK button.
The Search, Playback, Video Enhancement, Print Image, Save
Video, Save Image, Backup functions are the same as the steps
in the Internet Explorer, please see page 60-68.

D-Link MYDLINK DNR-322L Specifications

Power

power adapter	DC 12V/4 A
max power consumption	25.20 W
standby state max power consumption	0.23 W

Operating Environment

operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
storage temperature	Operating: 5% to 90% (non-condensing)

Memory

flash rom	128 MB
ram	256 MB DDR II

Weight and Dimensions

dimension	4.53 x 5.76 x 7.03 inches (115 x 146.4 x 178.5 mm)
weight	0.875 kg (1.93 lbs)
