D-Link MYDLINK DNR-322L User Manual

58D-Link DNR-322L User Manual
Section 3 - Conguration
Live Video
Setup Live View
Step 1: Click the LIVE VIDEO button at the top of the menu.
Step 2: Select a camera(s) from the camera list on the right and then drag it to the location to where you wish the image to
be displayed.
Step 3: Users can change the video display position by drag it to another position.
Note
1. The selected video will be marked with a green line.
2. Enable Digital PTZ: Right click on the video and enable xClick the + or – button to zoom in or zoom out the view. The lower right square ashing
on the video grid indicates the correspondent view of the camera.
3. If the camera supports PTZ, users can control the selected camera from the PTZ panel. Users can also right click on the video and check Enable
Move to control the PTZ function directly. Please note that when Enable Move is checked, the video will be marked with a red outline. This indicates
that another camera cannot be adjusted until the PTZ function has been deactivated.
4. If the camera supports audio, users can check Enable Audio from the right click menu and listen to live audio of this channel.
5. Snapshot: Right click on the video and select the snapshot function to capture a specic video image immediately.
6. Right clicking on the video will show the option to Toggle to Full Screen. Press the ESC button on the keyboard to return to normal display.
This section will enable you to congure and view the live video from your network cameras.
Drag and Drop
or double click

D-Link MYDLINK DNR-322L Specifications

Power

power adapter	DC 12V/4 A
max power consumption	25.20 W
standby state max power consumption	0.23 W

Operating Environment

operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
storage temperature	Operating: 5% to 90% (non-condensing)

Memory

flash rom	128 MB
ram	256 MB DDR II

Weight and Dimensions

dimension	4.53 x 5.76 x 7.03 inches (115 x 146.4 x 178.5 mm)
weight	0.875 kg (1.93 lbs)
