D-Link MYDLINK DNR-322L User Manual

59D-Link DNR-322L User Manual
Section 3 - Conguration
1/4/6/9/16/N
Split Screen:
View E-Map:
Auto Scan:
Full Screen:
PTZ Camera
Control:
Zoom:
User can choose to view 1/4/6/9/16 or NxN cameras at a time.
Note:Maximumphysicalcamerasonlysupports9channels,otherchannelsarethe“Duplicatedchannel”.
Displayyouremaple.Max.size20KBytesofBMPandJPGle
Activate auto scan to rotate the channels on the display screen. For instance, you may select to show only 4-split screen on the
liveview, while connecting 16 channels to the system. With auto scan function, you are able to see all 16 channels by turns.
Select to display the video with full screen. Press ESC button on the keyboard to return to normal display.
You may control the camera view by utilizing the PTZ camera control panel to adjust the camera’s view. This is only available with
cameras that support the PTZ function.
Click the + or - button to zoom in or zoom out. This option is only available with cameras that support the optical zoom function.
Camera List
1/4/6/9/16/N Split Screen
Full Screen
View E-Map
PTZ Camera Control
Zoom
Auto Scan

D-Link MYDLINK DNR-322L Specifications

Power

power adapter	DC 12V/4 A
max power consumption	25.20 W
standby state max power consumption	0.23 W

Operating Environment

operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
storage temperature	Operating: 5% to 90% (non-condensing)

Memory

flash rom	128 MB
ram	256 MB DDR II

Weight and Dimensions

dimension	4.53 x 5.76 x 7.03 inches (115 x 146.4 x 178.5 mm)
weight	0.875 kg (1.93 lbs)
