D-Link Wireless AC1200 User Manual

5D-Link DIR-850L User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power LED
A solid green light indicates a proper connection to the power supply. The light will be solid orange during boot-up
and will blink green during the WPS process.
2 Internet LED
A solid green light indicates a connection to the Internet port. If the LED is orange, the connection is good but
the router cannot connect to the Internet. If this LED is blinking orange, this indicates that the “on demand”
connection type is set and the Internet connection is idle.
1
2

D-Link Wireless AC1200 Specifications

General

Wireless Speed	1200 Mbps
LAN Ports	4 x 10/100/1000 Mbps
WAN Port	1 x 10/100/1000 Mbps
Wireless Standard	802.11ac
Frequency Bands	2.4 GHz, 5 GHz
Security	WPA, WPA2
Antenna Type	External
