D-Link Wireless AC1200 User Manual

10D-Link DIR-850L User Manual
Section 2 - Installation
5. Plug the power adapter into your router and connect to an available power outlet or surge protector. If the
Power LED does not light up, press the Power button on the back of the router.
6. After the router has powered up, verify that the Power (green) and Internet (green or orange) LEDs are both lit.
Proceed with router conguration.
12V
2A
USB
WPS
1
2
3
LAN
4
INTERNET
POWER
Modem
DIR-850L
Computer

D-Link Wireless AC1200 Specifications

General

Wireless Speed	1200 Mbps
LAN Ports	4 x 10/100/1000 Mbps
WAN Port	1 x 10/100/1000 Mbps
Wireless Standard	802.11ac
Frequency Bands	2.4 GHz, 5 GHz
Security	WPA, WPA2
Antenna Type	External
