1TECHNICAL DATA
Internal and external cab components LF45/55 series
1-6
Field of vision d imensions
B
3
B
4
B
2
B
1
A
1
A
3
D
1
C
1
C
3
C
4
C
2
A
2
B
5
B
A
C
D
K100237
Mirror size 1 size 2 size 3 size 4 size 5
Pavement mirror [A] 1m 1m 1.25 m
Wide-angle mirror [B] 2.5 m 15 m 12.5 m 25 m 3m
Main mirror on co-driver’s
side [C]
30 m 3.5 m 0.75 m 4m
Main mirror on driver’s
side [D]
10 m 2.5 m
0
ǹ 0210
