LF45/55 series General
INTERNAL CAB COMPONENTS
2-1
2. GENERAL
2.1 OVERVIEW DRAWING, INTERIOR CAB COMPONENTS
K1 01 438
1 2 3 4 6 7 8 9 10
11
12
13
14
151617
5
Legend
1. Left-side ventilation grille
2. Instrument panel
3. Garnish moulding
4. Radio panel
5. Frame rim cover panel
6. Upper dashboard panel on driver’ s side
7. Central console control panel
8. Upper side of cover panel
9. Upper side of cover
10. Right-side ventilation grille
11. Right-side dashboard panel
12. Lid on central box
13. Lower dashboard panel on co-driver’s side
14. Ashtray
15. Engine tunnel dashboard panel
16. Lower dashboard panel on driver’ s side
17. Steering column dashboard panel
2
ǹ 0210
