LF45/55 series Removal and installation
INTERNAL CAB COMPONENTS
4-31
4.11 REMOVAL AND INSTALLATION, INTERIOR LIGHTING
Removing the interior ceiling lighting
1. Put a screwdriver between the glass cover
(1) and the holder (2).
2. Remove the glass cover (1).
K1 01 169
1
2
3. Bend the lock levers (B) inwards.
4. Unplug the connectors and remove the
lamp holder.
Fitting the interior ceiling lighting
1. Bend the lock levers (B) outwards.
2. Hook up the connectors and fit the lamp
holder (2).
3. Fit the glass cover (1).
K1 00 617
B
4.12 REMOVAL AND INSTALLATION, IGNITION LOCK
Removing the ignition lock
1. Remove the covers around the steering
column under the steering wheel.
2. Disconnect the connectors (behind the
dashboard).
3. Drill off the head of the security bolt, use a
bit with the same diameter as the hole
where the head falls and remove the
ignition lock.
Installing the ignition lock
1. Install the ignition lock.
2. Tighten the security bolts with such a
tightening torque that the heads break off.
3. Fit the covers around the steering column.
K1 01 134
2
ǹ 0210
