1
INTERNAL CAB COMPONENTS
Removal and installation LF45/55 series
4-34
4.14 REMOVAL AND INSTALLATION, DOOR LOCK CYLINDER
Removing the door lock cylinder
1. Remove the complete door lock
mechanism.
2. Remove the circlip (3).
3. Detach the operating lever (4).
4. Loosen the locking spring (1) and remove
the door lock cylinder (2).
Fitting the door lock cylinder
1. Fit the door lock cylinder (2). Fit the locking
spring (1).
2. Fit the operating lever (4).
3. Fit the locking ring (3).
4. Fit the complete door lock mechanism.
123 4
K1 01 440
4.15 REMOVAL AND INSTALLATION, ENGINE BRAKE SWITCH
Removing the engine brake switch
1. Remove the covers from the steering
column.
2. Remove the engine brake switch connector
from the connector holder next to the
steering column.
3. Remove the attachment bolts (1) from the
engine brake switch.
4. Remove the engine brake switch (2).
Installing the engine brake switch
1. Fit the engine brake switch (2).
2. Secure the attachment bolts (1).
3. Fit the connector.
4. Fit the steering column covers.
1
2
K1 01 164
2
ǹ 0210
