LF45/55 series Removal and installation
INTERNAL CAB COMPONENTS
4-17
4.5 REMOVAL AND INSTALLATION, STEERING COLUMN
Note:
A steering wheel with an airbag can be
recognised by the inscription ”airbag” on the
cover plate and the ”Airbag” sticker on the
windscreen.
Steering wheel model without airbag
Removing the steering column without
airbag steering wheel
1. Place the steering box in the central
position using the marks.
S7 00 623
2. Remove the steering column panel.
3. Depending on the work to be carried out,
remove the floor dust cover or the cover
panels beneath the steering wheel.
4. If applicable, remove the steering column
adjustment air pipe.
5. Remove the connectors from the steering
column.
6. Remove the attachment bolt of one
universal joint of the steering shaft
(depending on the operations to be
performed; either the universal joint beneath
the steering wheel or the universal joint on
the steering box). Before loosening, mark
the position of the universal joint versus the
steering shaft.
7. Remove the attachment bolts. One of the
attachment bolts is a security bolt. Remove
this using a drift.
8. Remove the steering column.
2
ǹ 0210
