DAF LF45 Series User Manual

1
LF45/55 series Removal and installation
INTERNAL CAB COMPONENTS
4-9
4.3 REMOVAL AND INSTALLATION OF COMPLETE DASHBOARD
K1 01 437
7
123
456
Removing the dashboard
1. Disconnect the earth lead from the battery
terminal.
2. Remove the attachment bolts and the panel
plug (6). Remove the steering column cover
panel.
3. Remove the attachment bolts (1), (2) and
(3) and remove the cover panel on
co-driver’s side.
4. Remove the attachment bolts (4) and the
panel plugs (5). Remove the engine tunnel
cover panel. Remove the connector from
the 12V power supply.
5. Remove the attachment bolts (7) and
remove the upper cover panel.
6. Open the grille.
2
ǹ 0210
