LF45/55 series Cab suspension
TECHNICAL DATA
2-1
2. CAB SUSPENSION
2.1 GENERAL
The day cab can be fitted with rubber spring
elements at the front. The version with rubber
spring elements at the front does not have a
stabiliser.
The coil spring elements are fitted with shock
absorbers.
The length of the spring elements and the cab
height cannot be adjusted.
On models equipped with coil spring elements at
the front, a difference in cab height can be
corrected to a certain extent using the stabiliser
bar.
At the rear, coil springs are used. The length of
the spring elements varies depending on
whether a day cab or a sleeper cab is involved.
Cab support, general
The distance between the cab
supports (A) measured from the
left side of the left support to the
left side of the right support is:
1000 mm
9
15
10
16
12
11
13
14
K1 00 575
ǹ 0210
