DAF LF45 Series User Manual

1
LF45/55 series Removal and installation
EXTERNAL CAB COMPONENTS
4-3
4.2 REMOVAL AND INSTALLATION, ENTRANCE STEP GRILLE
Removing the stepwell and entrance step
support
1. Remove the attachment bolts (1) from the
stepwell.
2. Remove the grille.
Installing the stepwell and entrance step
support
1. Fit the grille.
2. Secure the grille with the attachment
bolts (1).
1
K1 00 987
4.3 REMOVAL AND INSTALLATION, ENTRANCE STEP SUPPORT
Removing the entrance step support
1. Tilt the cab forward.
2. Remove the attachment bolts (1).
3. Remove the bracket from the entrance step.
Installing the entrance step support
1. Fit the bracket.
2. Secure the bracket with the attachment
bolts (1).
3. Tilt the cab back.
1
K1 01 151
4
ǹ 0210
