EXTERNAL CAB COMPONENTS
Removal and installation LF45/55 series
4-2
K1 00 984
1
4
2
5
5
5
3
2. Remove the hose for the windscreen wiper
fluid (1).
3. Remove the protecting plate (2).
4. Remove the connectors (3).
5. Remove the attachment nut (4).
6. Remove the attachment bolts (5) and
remove the windscreen wiper mechanism.
Installing the windscreen wiper mechanism
1. Fit the windscreen wiper mechanism with
the attachment bolts (5).
2. Fit the attachment nuts (4).
3. Fit the connectors (3).
4. Fit the protecting plate (2).
5. Fit the hose for the windscreen wiper
fluid (1).
6. Put the windscreen washer motor in the
neutral position by turning it on and off
quickly using the switch in the cab.
7. Fit the windscreen wiper arms.
4
ǹ 0210
