LF45/55 series Removal and installation
CAB SUSPENSION
4-11
4. Remove the attachment bolts (1) and (2).
5. Remove the coil spring element.
Installing front spring suspension
1. Put the spring element in place.
2. Fit the attachment bolt (1) in the cab
support with the bolt head on the inside.
3. Fit the attachment bolt (2) in the chassis
support with the bolt head on the outer side.
4. Remove the hoisting belt.
5. Fit the headlight cover panel and secure it
with the attachment bolts.
K1 01 205
2
1
4.7 REMOVAL AND INSTALLATION, REAR COIL SPRING SUSPENSION
Removing rear coil spring suspension
1. Tilt the cab forward.
2. Remove the attachment bolt (1) at the top of
the spring element.
3. Remove the attachment bolt and nut (2) at
the top.
4. Remove the spring element.
Installing rear coil spring suspension
1. Put the spring element in place.
2. Hand-tighten the attachment bolt (1).
3. Fit the attachment bolt and nut (2) and
hand-tighten them.
4. Tilt the cab back.
5. Tighten the attachment bolts and nuts
(1), (2).
K1 01 162
1
2
5
ǹ 0210
