LF45/55 series Removal and installation
CAB SUSPENSION
4-7
Installing the front silent block
1. Place the housing of the cab support on the
base (1).
K1 01 537
6
1
2. Place the silent block, its openings in the
right positions (angle A), on the housing of
the cab support, see ”Technical data”.
A
K1 01 442
3. Force the silent block into the housing using
the press-in tool (6) of the special tool
(DAF no. 1329471).
Installing the rear silent block
1. Place the back-up washer (3) on the
base (1).
2. Place the housing of the cab support on the
base (1) with the back-up washer (3).
3. Force the silent block into the housing using
the press-in tool (4) of the special tool
(DAF no. 1329471).
K1 01 536
4
3
1
5
ǹ 0210
