CAB SUSPENSION
Removal and installation LF45/55 series
4-14
6. Fit the hoisting belt to support the cab.
K1 01 212
7. Remove the cover from the cab
lead-through and remove the positive cable
(2).
8. Remove the connectors (1).
9. Remove the wiring harness attachment.
10. Remove the air pipes from the cab
lead-through.
1
1
2
G0 00 203
11. Disconnect the air pipes (2) from the service
brake valve.
12. Remove the clutch cylinder pipe (3). Collect
the clutch fluid.
13. Remove the earth lead (1).
14. Remove the (air) pipe attachment.
15. Remove the lifting cylinder pin.
MAXI
P M
AX 4 BAR
MINI
K1 01 214
1
3
2
5
ǹ 0210
