LF45/55 series Disassembly and assembly
CAB TILTING GEAR
5-3
7. Check seal (13) and replace if necessary.
8. Turn the plunger housing (12) with the seal
(13) and copper washer (14) in the pump
housing (24).
Note:
The bevelled side of the seal (13) points in
the direction of the plunger housing (12).
9. Fit the grooved ring (11) and the plunger
(10) in the plunger housing (12).
10. Fit the spring (9), the spring washer (8) and
the circlip (7).
11. Fit a new gasket to the pump housing (24).
12. Fit the pump housing (24) in the reservoir
(1) in line with the marks.
13. T ighten the socket head screws.
6
ǹ 0210
