LF45/55 series Inspection and adjustment
SEATS
3-1
3. INSPECTION AND ADJUSTMENT
3.1 INSPECTION, SEAT BELT OPERATION
- Pull the belt quickly out of its retracting unit
to test the locking action. The belt must
lock. It must not be possible to pull the belt
out any further after locking.
- Check the seat belts for wear.
3.2 ADJUSTI NG THE CONTROL CABLE OF T HE HEIGHT CONT ROL VALVE
Adjusting the control cable of the height
control valve
1. Remove the seat squab.
2. Loosen the lock nut of the cable
tensioner (1).
3. Set the seat in its highest position.
4. Adjust the distance (X) between the
operating lever (2) of the height control
valve and the bottom air bellows carrier (3)
to the prescribed distance, see ”Technical
data”.
X
2
1
3
K1 01 377
7
ǹ 0210
