1SEATS
Removal and installation LF45/55 series
4-14
9. Disconnect the air pipes (11) (red) and (12)
(yellow) from the quick-release coupling to
the height control valve.
10. Disconnect the air pipe (11) of the air
bellows from the quick-release coupling (8).
11. Remove the complete manifold (2) with
pipes from the seat frame.
Installing manifold
1. Repair the air supply pipe to the new
manifold (2) using the repair kit (4) supplied.
2. Fit the manifold (2) on the seat frame.
3. Fit the control cable (5) in the pipe guide
(7). Fit the pipe guide (7) in the attachment
clamp (10).
4. Fit the pipe guide (6).
5. Lay the pipes back into the original position
(before removal) in the pipe clips (6 and 7).
6. Connect the air pipe (11) of the air bellows
to the quick-release coupling (8).
7. Connect the air pipes (11) (red) and (12)
(yellow) to the height control valve.
8. Fit the rapid-lowering handle.
9. Remove the seat lock.
10. Check the pipes and system for air
tightness and proper operation.
11. Fit the seat squab.
7
ǹ 0210
