INTERNAL CAB COMPONENTS
Removal and installation LF45/55 series
4-14
15. Fit the connecting block via the inside and
press it firmly into the retainers (2).
16. Fit the connectors (1) to the connecting
block. Pay attention to the markings on the
components.
K1 00 994
2
1
1
17. Fit the protective cover to the cab lead
through and secure it using the attachment
bolt (1).
K1 00 988
1
2
18. Close the grille.
19. Fit the attachment bolts under the
dashboard to the left and right.
20. Secure the attachment bolts in the window
frame.
21. Fit the dashboard panels on co-driver’s
side.
22. Fit the steering column dashboard panels.
23. Fit the connector of the 12V power supply to
the engine tunnel cover panel.
24. Fit the cover panel to the engine tunnel.
25. Fit the earth lead to the battery terminal.
2
ǹ 0210
