LF45/55 series Removal and installation
CAB HEATING
3-19
Installing the heating radiator
1. Install the heater radiator in the heating unit.
2. Press the heater radiator into the retainer.
3. Fit the heater radiator attachment bolts.
4. Fit new O-rings and fit the heater pipes.
5. Secure the heater pipe with the attachment
bolt.
6. Fit the heater valve holder and secure it
using the attachment bolts.
7. Fit the control cable to the heater valve and
secure it using the fastening clip.
8. Install the heater motor.
9. Fit the air conditioning thermostat
connectors and the series resistor.
10. Fit the heater motor cover.
11. Fit the heater unit.
3
ǹ 0210
