Local Configurations 114
Figure 5-82
Enable the Batch Modify function. Step 3
Configure the settings for start IP address (the IP address is allocated in sequence), Step 4
subnet mask, default gateway, user name, and password.
Enable the Add function to add the devices into the Added Device area. Step 5
Click Apply to save the settings. Step 6
5.6.1.6 Exporting IP Address
You can export the added IP address to the USB storage device.
The exported information is saved in .csv file, which includes IP address, port number, channel
number, manufacturer, user name, and password.
Insert the USB storage device to the USB port of the Device. Step 1
Click Export. Step 2
The Browse interface is displayed. See Figure 5-83.
