Dahua ITC237-PU1B-IR - Camera Settings

31
Parameter
Note
Control Type
The alarm can be triggered by different ways:
 White list gate: to capture white or white list of fuzzy matching
vehicles, the output opening signal.
 All car gate: to capture any vehicle, the output opening signal.
 Command gate: the platform issued a command, the output gate
signal.
Hand On
Click it to manually trigger output open barrier signal.
Hand Off
Click it to manually trigger output close barrier signal.
Note:
For ITC237-PU1B-IR, ITC237-PU1B-L only
Open config,
close config
 Alarm output: start alarm linkage output port, you can choose any of the
two ports.
Note:
For ITC237-PU1B-IR, ITC237-PU1B-L only.
 Output delay: the duration of the opening or closing signal.
Table 4-7
4.1.7 Intelligence Default
The intelligence default interface is shown as in Figure 4-17 Intelligence Default.
Click on default to restore default settings.
Note: You cannot restore IP address and other network info.
Figure 4-17 Intelligence Default
4.2 Camera
4.2.1 Attribute
4.2.1.1 General
The general interface is shown as in Figure 4-18. Here you can set camera parameters. For different
models, you shall refer to its parameter. Setup in this interface comes effective immediately.
