172
same time.
Figure 5-29
5.10.1.2 Image
Note
Slight difference may be found since the connected network camera may not be same model.
Here you can view device property information. The setups become valid immediately after you set. See
Figure 5-30.
Figure 5-30
Please refer to the following sheet for detailed information.
Please select a channel from the dropdown list.
It divides one day (24 hours) to two periods. You can set
different hue, brightness, and contrast for different periods.
It is to adjust monitor video brightness and darkness level. The
default value is 50.
The bigger the value is, the large the contrast between the bright
and dark section is and vice versa.
It is to adjust monitor window brightness. The default value is 50.
The larger the number is , the bright the video is. When you
