61
Please following the steps listed below to draw the period manually.
Step 1 Select a channel you want to set. See Figure 4-25.
Figure 4-25
Step 2 Set record type. See Figure 4-26.
Figure 4-26
Note
When the record type is MD (motion detect), alarm, MD&Alarm, please enable the channel
record function when corresponding alarm occurs. For example, when the alarm type is MD,
from main menu->Setting->Event->Video Detect->Motion Detect, please select the record
channel and enable record function. See Figure 4-27.
When the record type is MD (motion detect), alarm, MD&Alarm, refer to chapter 4.7.1 Video
detect, chapter 4.7.2 Alarm Settings.
Figure 4-27
Step 3 Please draw manually to set record period. There are six periods in one day. See Figure
4-28.
Note
If you have added a holiday, you can set the record period for the holiday.
