User's Manual
222
Select the check box and select the needed recording channel
(support multiple choices). When an alarm occurs, the NVR
device activates the channel for recording.
You need to enable intelligent recording and auto recording first.
For details, see "4.1.4.6 Schedule".
Select the check box and click Setting to select the channel and
PTZ action. When an alarm occurs, the NVR device associates
the channel to perform the corresponding PTZ action. For
example, activate the PTZ in channel one to turn to the preset
point X.
● Tripwire alarm supports to activate PTZ preset point only.
● You need to set the corresponding PTZ actions first, see
"4.4.4 Calling PTZ Functions".
At the end of the alarm, the recording extends for a period of time.
The time range is from 10 seconds to 300 seconds.
Select the check box and select the channel for tour. When an
alarm occurs, the local interface of the NVR device displays the
selected channel screen.
● You need to set the time interval and mode for tour first, see
"4.17.2 Tour".
● After the tour is over, the preview interface is restored to the
screen split mode before the tour.
Select the check box, the NVR device records the alarm
information in the log when an alarm occurs.
Check the box and then select the corresponding audio file from
the dropdown list. System plays the audio file when the alarm
occurs.
Refer to "4.18.1 File Management" to add audio file first.
Select the check box to activate the buzzer when an alarm
occurs.
Step 9 Click
OK
, system goes back to human face recognition interface.
Step 10 Click
Apply
to complete the settings.
The interface is shown as Figure 4-131 if there is matched result.
