User's Manual
230
Figure 4-138
2) Configure the parameters. See Table 4-38.
Table 4-40
Set the intrusion action, including appear and crossing area.
Set the direction to cross the area, including enter, exit and both.
Click to filter the target. Check the blue wireframe and adjust the
size of the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum size),
that is, when the passing target is smaller than the minimum target or
larger than the maximum target, no alarm will be generated. The
maximum size should not be smaller than the minimum size.
Select AI recognition and the system displays alarm target. The
default selection is person and motor vehicle and system
automatically identifies the person and motor vehicle appeared within
the monitoring range.
3) Press and hold down the left button on the monitoring screen to draw the
monitoring area.
4) Click
OK
to complete the rule setting.
Step 3 Click , you can refer to "4.7.2.4.1 Tripwire" to set other parameters.
Step 4 Select
Enable
check box and click
Apply
to complete the intrusion setting.
