User's Manual
323
Figure 4-221
Step 2 Configure the settings for the SNMP parameters. See Table 4-73.
Table 4-73
Enable the SNMP function.
Select the check box of SNMP version(s) that you are using.
The default version is
V3
. There is a risk of select V1 or V2.
Indicates the monitoring port on the agent program.
Indicates the read/write strings supported by the agent program.
Indicates the destination address for the agent program to send the
Trap information.
Indicates the destination port for the agent program to send the Trap
information.
Enter the user name that is allowed to access the Device and has
the "Read Only" permission.
Enter the user name that is allowed to access the Device and has
the "Read and Write" permission.
Includes MD5 and SHA. The system recognizes automatically.
